Output Rating
Current rating: 50 mA maximum
Black wire specifications per configuration
IO-Link Push/Pull
Output High: ≥ Vsupply - 2.5 V
Output Low: ≤ 2.5 V
PNP
Output High: ≥ Vsupply - 2.5 V
Output Low: ≤ 1V (loads ≤ 1 MegΩ)
NPN
Output High: ≥ Vsupply - 2.5 V (loads ≤ 50 kΩ)
Output Low: ≤ 2.5 V
White wire specifications per configuration
PNP
Output High: ≥ Vsupply - 2.5 V
Output Low: ≤ 2.5 V (loads ≤ 70 kΩ)
NPN
Output High: ≥ Vsupply - 2.5 V (loads ≤ 70 kΩ)
Output Low: ≤ 2.5 V
Typical Excess Gain for the 2000 mm Model
Table 2: High Excess Gain (Standard Excess Gain) Using a 90% White Card
Response Speed (ms) at 100 mm at 500 mm at 1000 mm at 2000 mm
3 125 50 15 4
5 125 50 15 4
15 575 (175) 250 (75) 70 (25) 15 (6)
25 1000 (650) 450 (250) 125 (70) 30 (15)
50 2000 (1000) 900 (450) 250 (125) 60 (30)
Standard excess gain available in 15, 25, and 50 ms response speeds; standard excess gain provides increase noise immunity.
Typical Excess Gain for the 5000 mm Model
Table 3: Typical Excess Gain Using a 90% White Card
Gain Modes at 50 mm at 600 mm at 1000 mm at 2000 mm at 5000 mm
Performance (Default) 50 400 400 175 30
Excess gain is consistent for 15, 50, and 250 ms response speeds. Excess gain is approximately 10% lower in 2 ms and 5 ms response speed modes.
Excess gain in black gain mode is approximately three times higher than in performance gain mode. It is useful for low reflectivity targets.
Excess gain in shiny gain mode is approximately one third the excess gain of performance gain mode values. It is useful for highly reflective targets.
Typical Excess Gain for the 10000 mm Model
Table 4: Typical Excess Gain Using a 90% White Card
Gain Modes at 50 mm at 600 mm at 1000 mm at 2000 mm at 5000 mm at 6000 mm at 7500 mm at 10000 mm
Performance
(Default)
50 400 400 175 30 20 10 5
Excess gain is consistent for 15, 50, and 250 ms response speeds. Excess gain is approximately 10% lower in 2 ms and 5 ms response speed modes.
Excess gain in black gain mode is approximately three times higher than in performance gain mode. It is useful for low reflectivity targets.
Excess gain in shiny gain mode is approximately one third the excess gain of performance gain mode values. It is useful for highly reflective targets.
Beam Spot Size
2000 mm Models 5000 mm Models 10000 mm Models
Distance (mm) Size (x × y) (mm) Distance (mm) Size (x × y) (mm) Distance (mm) Size (x × y) (mm)
100 2.6 × 1.5 100 6 × 4 100 7 × 6
1000 4.2 × 2.5 2500 11 ×7 2500 16 × 11
2000 6 × 3.6 5000 15 × 11 5000 25 × 19
7500 32 × 25
10000 41 × 31
Beam spot size is calculated as 1.6 times the D4σ measured value
Q5X Laser Measurement Sensor with Dual Discrete Outputs and IO-Link
P/N 208795 Rev. G www.bannerengineering.com - Tel: + 1 888 373 6767 11
