When in mode, displays when (-)(MODE) is pressed and held. To access the manual adjust options, briefly press
and release (+)(CH1/CH2) or (-)(MODE). To enter TEACH mode, press the (SELECT)(TEACH) button and hold for longer than 2
seconds.
To enter mode, hold and press four times. To enter mode, hold and press seven times. Holding
and pressing four times unlocks the sensor from either lock mode and the sensor displays .
Specifications
Sensing Beam
Visible red Class 2 laser models, 650 nm
Supply Voltage (Vcc)
10 to 30 V DC (Class 2 supply) (10% max ripple within limits)
Supply Protection Circuitry
Protected against reverse polarity and transient overvoltages
Power and Current Consumption, exclusive of load
2000 mm model: < 1 W
5000 mm model: < 1.4 W
Sensing Range
2000 mm model: 95 mm to 2000 mm (3.74 in to 78.74 in)
5000 mm model: 50 mm to 5000 mm (2 in to 16.4 ft)
10000 mm model: 50 to 10000 mm (2 in to 32.8 ft)
Output Configuration
Channel 1: IO-Link, Push/pull output, configurable PNP or NPN output
Channel 2: Multi-function remote input/output, configurable PNP or NPN, or
pulse frequency modulated output
Construction
Housing: ABS
Lens cover: PMMA acrylic
Lightpipe: polycarbonate
Connector
Integral 4-pin M12 male quick-disconnect connector
Boresighting
2000 mm model: ± 43 mm at 2000 mm
5000 mm model: ± 86 mm at 5000 mm
10000 mm model: ± 172 mm at 10000 mm
Response Speed
2000 mm model: User selectable 3, 5, 15, 25, or 50 ms
5000 mm model: User selectable 2, 5, 15, 50, or 250 ms
10000 mm model: User selectable 2, 5, 15, 50, or 250 ms
Delay at Power Up
< 2.5 s
Maximum Torque
Side mounting: 1 N·m (9 in·lbs)
Ambient Light Immunity
2000 mm model:
5000 lux at 1 m
2000 lux at 2 m
5000 and 10000 mm models: 5000 lux
Temperature Effect (Typical) for 2000 mm Models
< 0.5 mm/°C at < 500 mm
< 1.0 mm/°C at < 1000 mm
< 2.0 mm/°C at < 2000 mm
Temperature Effect (Typical) for 5000 and 10000 mm Models
< 0.5mm/°C for up to 3000 mm
< 0.75mm/°C for up to 5000 mm
< 2.0 mm/C for up to 7500 mm
< 6.0 mm/C for up to 10000 mm
Remote Input
Allowable Input Voltage Range: 0 to Vsupply
Active High (internal weak pull-down): High state > (Vsupply – 2.25 V) at 2
mA maximum
Active Low (internal weak pull-up): Low state < 2.25 V at 2 mA maximum
IO-Link Interface
IO Link Revision V1.1
Smart Sensor Profile: Yes
Baud Rate: 38400 bps
Process Data In Length: 32 bits
Process Data Out Length: 8 bits
Minimum Cycle Time: 3.6 ms
IODD files: Provides all programming options of the display, plus additional
functionality.
Application Note
For optimum performance, allow 10 minutes for the sensor to warm up for
the 2000 mm models and 20 minutes for the 5000 and 10000 mm models.
Environmental Rating
IP67 per IEC60529
Vibration
MIL-STD-202G, Method 201A (Vibration: 10 Hz to 55 Hz, 0.06 inch (1.52
mm) double amplitude, 2 hours each along X, Y and Z axes), with device
operating
Shock
MIL-STD-202G, Method 213B, Condition I (100G 6x along X, Y, and Z axes,
18 shocks), with device operating
Operating Conditions
–10 °C to +50 °C (+14 °F to +122 °F)
35% to 95% relative humidity
Storage Temperature
–25 °C to +70 °C (–13 °F to +158 °F)
Advanced Capabilities
Q5X Laser Measurement Sensor with Dual Discrete Outputs and IO-Link
10 www.bannerengineering.com - Tel: + 1 888 373 6767 P/N 208795 Rev. G
