6.5.10 Monitor the Scanner
When in the Monitoring mode, the graph displays the current working area of the scanner. Use this function to verify that
the designed Safety and Warning Zones are designed correctly (provide the desired protection). This function is also used
to watch the functioning of the scanner during operation. The Monitoring function is only available when an online scanner
has been selected.
Tip: If you click on Monitoring and receive a message that the scanner is busy, verify that the software
has access through the Window's firewall.
On the left panel, the software displays the scanner status (if it is currently functioning). It is also possible to view some
parameters like response time by clicking on the Parameters icon, view pin assignments by clicking on the Connector icon,
or view fault information by clicking on the Diagnostic icon.
The following icons, located on the right side of the graph, allow the users to manipulate the display.
Icon Function
Saves the Monitoring information into a .txt file
Moves the graph origin on the page.
After clicking on the button, click and hold on the graph to move it around (up, down, right or left). After you position the
graphic, release the mouse button. Click on the icon again to set the location.
Toggles the graph polar (r, θ) and Cartesian (x, y) coordinates.
Toggles the graph unit of measure between mm and inches.
Zooms in on the graph.
Zooms out on the graph.
6.5.11 Save a Configuration File
After a configuration is complete or even partially created, you may save your file to your hard drive.
1.
Go to File > Save.
2. Browse to the location on your hard drive to save the file to.
3.
Name your
configuration file.
4. Click Save.
6.5.12 Edit an Existing Configuration
To edit an existing configuration, follow these steps.
1.
To edit an existing configuration on your hard drive, follow these steps:
a) In the software, select the file folder icon or go to File > Open Safety System Configuration from PC.
b) Browse to the file location on your hard drive and select it.
c)
Click Open.
SX5 Safety Laser Scanner
www.bannerengineering.com - Tel: +1.763.544.3164 73
