R5900103 /02 C-10, C-532
Reach Adjustable with signal strength modulation; max. 30m (100 ft) between
ClickShare Button and ClickShare Base Unit
Frequency band 2.4 GHZ and 5 GHz
Frequency band 2.4 GHZ and 5 GHz (DFS channels supported in select number of
countries)
Connections 1x Ethernet LAN 1Gbit
1x USB Type-C 2.0 (front); 1x USB Type A 2.0 (front)
Temperature range Operating: 0°C to +40°C (+32°F to +104°F)
Max: 35°C (95°F) at 3000m
Storage: -20°C to +60°C (-4°F to +140°F)
Humidity Storage: 0 to 90% relative humidity, non-condensing
Operation: 0 to 85% relative humidity, non-condensing
Anti-theft system Kensington lock
Certifications FCC/CE
Touch screen support &
Interactivity
Yes
Room Dock (peripheral
support)
No
Local view & moderation Local view and moderation*
Network connection LAN & WiFi
Management and reporting Yes
Warranty 1 year standard. 5 years coverage via SmartCare
* * depends on configuration, available in future firmware updates
Base Unit C-5
Dimensions (HxWxD) 34 mm x 135 mm x 135 mm
Power supply Standard 110/220 V AC plug
Power consumption Operational: 5-10W, 24W Max
Weight 900 gr
Operating system Windows 8/8.1/10. macOS 10.13 and higher.
Android v9 and higher (ClickShare App)*
iOS 12 and higher (ClickShare App)*
Video outputs 4K UHD (3840*2160) @ 30Hz. HDMI 1.4b
Audio output HDMI
USB 1 X USB-A, 1 X USB-C
ClickShare Buttons 0
ClickShare App Desktop & Mobile
Native protocols Airplay, Google Cast, Miracast
C-10, C-5 Specifications
