30User Manual - Basic setupCR series
User Manual - Basic setup
5.7.2 X-PORT 3G-SDI
The X-PORT 3G-SDI module is an X-PORT2 interface module to support all SDI, HD-SDI and
3G-SDI formats.
5.7.2.1 Connectivity
PARAMETER VALUE
Main connectors 2xBNC-F
Input A1, Input B1
Redundancy connectors 2xBNC-F
Input A2, Input B2
Video formats - SDI (SMPTE 259M, up to 360 Mbps)
- HD-SDI (SMPTE 292M, up to 1.485 Gbps)
- 3G-SDI (SMPTE 424M/425M, up to 3.0 Gbps)
Nominal impedance 75 Ohms
Scan format Interlaced or progressive
Return loss <-15 dB, DC @ 1 MHz to 1.5 GHz
Clock rate Up to 3 Gbit/s (3G-SDI)
Maximum resolution 1920x1080p@60Hz
5.7.2.2 Cable Lenghts
PARAMETER VALUE
3G-SDI Max 100 m (RG-5 18 AWG/1694A)
HD-SDI Max 110 m (RG-5 18 AWG/1694A)
SDI Max 400 m (RG-5 18 AWG/1694A)
5.7.3 X-PORT HDMI 3D
The X-PORT HDMI 3D module is an X-PORT2 interface module to support various 3D for-
mats from the HDMI 3D specification.
5.7.3.1 Connectivity
PARAMETER VALUE
Main connectors 2xHDMI Type A
Input A, Input B
Video formats 720p or 1080p
Scan format Progressive only
Clock rate Up to 225 MHz
Maximum resolution 1920x1080p@60Hz
5.7.3.2 3D modes supported
RESOLUTION REFRESH HDMI 3D MODE
1080p 60Hz, 50 Hz Side by side, Top/Bottom
1080p 24 Hz Side by side, Top/Bottom, Frame packed
720p 60Hz, 50 Hz, 24 Hz Side by side, Top/Bottom, Frame packed
