4. Lamp & Lamp House
CAUTION: E xp ired xenon lamps.
Dispose of expired bulbs that are beyond warranty in the following manner: wrap the bulb tightly in several
layers o f canvas or heavy cloth. Place it on hard su rface and shatter the envelope with a sh arp ham m er blow.
DO NOT p lace a n on sh attered bulb in an y ordinary refuse container.
When returning a xenon lamp for warranty adjustment, pack it in its original shipping container. Complete
and return all required warranty information.
4.4 Installation of the Xenon lamp
WARNING: DO NOT P ERMIT UNAUTHO RIZED PERSONNEL TO PERFORM O R ATTEMPT ANY PHASE OF
XENON LAM P HA NDLING OR SERVICE. ONLY TRAINED AND QUALIFIED TECHNICAL SERVICE PERSONN EL
ARE ALLOWED TO HANDLE THE XEN ON LAMP.
WARNING: This procedure may only be performed by qualified technical service personnel.
CAUTION: Xenon comp act arc lamps are highly p ressu rized. W hen ignited, the norm al operating temperature
of the bulb increases the pressure to a level at which the bulb may explode if not handled in strict accord ance
to the manufacturer’s instructions. The bulb is stable at room temperature, but may still explode if dropped or
otherwise mishandled. W hen ever the lamp house, containing a xenon lamp , has to be dism antled or when ever
the protective container or cloth has to be removed from the xenon lamp , authorized protective clothing MU ST
be worn!
WARNING: Always wear fa ce pro tection (full face shield with neck protector) when handling xeno n lamps.
WARNING: Alw ays wear protective clothing (welder’s jacket) when handling x enon lamp s.
WARNING: Alwa ys wear clean leather gloves w ith w rist protectors w hen handling xen on lamps.
Necessary tools
• 17 mm open ended wrench.
• Torque wrench with 17 mm hexagon socket
• Torque wrench with 5 mm Allen socket.
Necessary parts
• Lamp cathode adapter.
• Hexagon s ock et head screw M6 x 40.
• Flat washer.
How to install the xenon lamp into the lamp house
1. Remove the UV blocker and side cover of the lamp house by releasing the retaining thumbscrews as illustrated.
Note: In case of a lamp replacement, the UV blocker will be already removed.
