R5905752 /16 DP2K C136
11.1 Removing the front dust filter
The front filter of the projector can be removed from the lamp side.
The filter can be cleaned.
Remove the dust filter
1. Remove the input cover of the projector, “Removal of the input cover”, page 124.
2. Release the captive screw of the front cover.
Pull the left side of the front cover 5 centimeters forwards. There is no need to remove the cover
completely.
Image 11–1 Dust filter access
3. Pull the small handle a little backwards and then to the front of the projector until the filter frame is
released.
4. Slide the filter to the left.
Maintenance
