4. Hardware orientation
4. HARDWA RE ORIENTATION
About this chap ter
This chapter explains the Event Mas ter series processo rs hardware in detail.
Overview
• Front pane l
• Rear panel
• SDI Input Card
• Dual Link DVI Input Card
• HDMI/DisplayPort Input Card
• Quad Channel DisplayPort O utput Card
• HDMI Output Ca rd
• SDI Output Card
• Expansion Link c ard
•VPUcard
