A. Specifications
A.3 Specifications of S3–4K
S3–4K Specifications
Video inputs
12 inputs via 3 input cards (Event Mas ter series cards)
• Up to 3 x 4K inputs - eac h input c ard supports up to 4K @60p
• 4 x SD/HD/3G SDI (6G rea dy)
• 4 x HDM I 1.4a (297 Mpix/sec max)
• 4 x DisplayP ort 1.1 (330 Mpix/sec max)
Video outputs
10 outputs via 3 output cards (Event Master series car ds)
• Up to 2x 4K outputs - each output c ard supports up to 4K@60 p
• 4 x SD/HD/3G SDI (6G rea dy)
• 4x HD MI 1.4a (297 Mpix/sec max)
• 2 x HDMI 1.4a for Multiviewer (297 Mpix/sec max)
Genlock Analog reference input/loop on BNC connec tors; bi-lev el and blac kburst at S D and
tri-level a t HD
S3D Sync: 4x input Din connector, 2x output Din connector
Program output
4 program outputs configur able as single screens or tiled/blended widesc reens
•Configurable from 4X 2048X1200@60 max to 1 x 4096x2400@60 max
• Independent edge blending/feathering control for all four sides
Scaled Aux outputs User defi nable from 4 x 2048x 1200@ 60 to 1 x 4K@6 0
Output color correction
Mixers
• Native resolution background mixer per output screen
• Independent layer transitions o r full P review/Program transition
• Flexiblelayerallocation–4mixableor8singlescalablePIP/keylayersassignab le
to any P rogram output screen
Still stores
Up to 100 HD stills available in background, A ux or PIP
Layer effects
• Borders (hard, soft, halo) and drop shadows
• Color effects
• Strobe, H&V flip
• Luma key
• PIP moves via Keyframes
Multiviewer
• Flexibl e user-d e finable layouts
• Monitor all Inputs and Outputs, including Preview and Aux
• Two outputs
• Dedicated hardware same as E2 Event Master Processor
Expandability
• Easily expa ndable for larger display applications via proprietary links
• Link units to increase available Inputs and Outputs for larger tiled/blended
widescreen applications
• Expansion via s imple linking - up to 4 chassis
• S3-4K s hips with the ability to link 2 chassis for expansion. Linking up to 4 chassis
will be available in a future software release.
HDCP HDCP c ompliant
Control
• Event Master screen management software for PC or MAC
• Ethernet RJ -45, 1000/100/10 Mbps autosense
Serviceability
• Field-Serviceable I/O and p rocessing cards (not hot-swappable)
• Hot-swappable dual-redundant power supplies
496 R5905948 EVENT MASTER DEVICES 17/07/2017
