A. Specifications
A.8 Specifications of EC-200
Overview
Features
• Robust Linux version of EventMa ster Toolset - same user interface used on Mac
and P C
• Onboard PC running Linux to support a purpose-built version of Event Master
toolset, enabling stand-alone usage
• Full c ontrol over the EventMaster Series switchers
• Simultaneous connection of multiple controllers, GUI interfaces, an d proce ssors
supported on sam e network. (Redundant backups of control)
• 2 internal 15.6-inch wide screen full HD (1,920x1,080) touchscreens with 10 point
multi touch
• 2 external monitors or touchs creens supported*
• High-resolution T-Bar for manual transitions
• 36 user-assignable buttons with customizable LCD labels
• Dedicated Background layer button
• 8 dedicated Layer selection buttons with multi-page functionality (shift pages for
destinations with 9 or m ore layers)
• 12 user-definable Destination buttons with multi-page functionality (easily supports
all the destinations available in future releases)
• Dedicated buttons fo r transition, live switching, modifying program, transitions, etc.
• 5 rotary encoders with wheels for ergonomic pip con trol and rapid placement of
resources
• 12 LCD Contextual Display Buttons to support the Syntax Programmer
• Tri Axis backlit trackball (based on function), with a very sm ooth rotary encoder for
the third axis and 4 buttons for cu rsor and position control
• 2 se parate gigabit Ethernet ne twork interface connections, one for Primary system
control, and one for supplem ental network control (additional IP address range
and m ode)
• Internal Solid State Hard drive
• 5 USB p orts for additional accessories such as external touchscreens, m ouse,
keyboard, thum bdrive, etc.
• Script lights, feedback LE Ds, and integrated work lights all dimmable
• Dust cover included
• Custom road case included
* N ote: The EC-200 DVI-D monitor connections do not support analog output. Digital
displays or digital to ana log converters are required.
Connectivity
• Controls m ultiple EventMaster S eries systems, including E2 and S3-4K
• Allows for an external control system to interact over a separate network interface
• Two additional DVI o utputs for m onitors to increase workspace, or add on up to 2
EC-50 for ultimate expansion
• Auto-ranging mains input (90-250VAC)
• External pointing device and K eyboards supported over U S B
Dimensions (HxWxD) 244.34 x 901.19 x 575.36 m m / 9.62 x 35.49 x 22.65 inches
Weight
20.41 kg (45 lbs)
R5905948 EVENT MASTER DEVICES 17/07/2017 503
