4.3.2 DisplayPort mode
About DisplayPort mode
The available DisplayPort (DP) modes for your display are:
• DP 1.2 MST
• DP 1.1 main
• DP 1.1 dual
Please refer to the technical specifications for an overview of accepted video formats.
To select the DisplayPort mode
1. Bring up the OSD main menu.
2. Navigate to the Input Select menu.
3. Enter the DP mode submenu.
4. Select one of the available DisplayPort modes and confirm.
4.3.3 4K SDI mode
About 4K SDI mode
The available 4K SDI modes for your display are:
• Square-division (SQD)
• 2-sample interleave (2SI)
• Auto
4K SDI mode is available on the MDSC-8427 12G version only.
To select the 4K SDI mode
1. Bring up the OSD main menu.
2. Navigate to the Input Select menu.
3. Enter the 4K SDI mode submenu.
4. Select one of the available 4K SDI modes and confirm.
4.3.4 SDI config
About SDI config
The available SDI config modes for your display are:
• Quad-SDI
• Dual SDI (12G and 3G)
• Single SDI-1
• Single SDI-3
SDI confi is only availbale for MDSC-8427 12G.
To select the SDI config mode
1. Bring up the OSD main menu.
2. Navigate to the Input Select menu.
3. Enter the SDI config submenu.
4. Select one of the available SDI config modes and confirm.
