3. Installation
3.3.3 Connecting to Video Sources
Wiring Diagram
3
Video Output
1
2
DVD Player, Set-top Box,
HDTV Receiver
5
6
+12V Relay Output
4
1
Power Cord
2
12V DC Jack
3
BNC Cable
4
DVI-D Cable
5
HDMI Cable
6
Composite Video Cable
