R5911438 /09 UDM78
6.1 Flight case
Flight case
The UDM flight case is designed to transport the UDM in a safe and secure manner, with or without being
mounted in its rigging frame. There's also sufficient space in the flight case to place the projector while
mounted in the UDM rigging frame. The four caster wheels, provided with breaks, and the eight handles make
the UDM flight case easy to handle. The floor of the flight case wagon is equipped with two small covered
compartments to store the remote control and the rigging clamps.
The flight case (empty) weight about ±47.5 kg (±105 lb).
Image 6–1 Flight case Image 6–2 Lift cover off.
Image 6–3 Projector assembled with Rigging frame. Image 6–4 Lift out the Projector.
WARNING: Maximum stack 2 UDM flight cases high. Never higher.
Flight case and rigging frame
