79R5911438 /09 UDM
6.2 Rigging frame
CAUTION: Projectors installed without rigging frame requires bracket(s) for safe installation if it is to
be placed in other positions than the ceiling or desktop. See “Wall or ceiling mount without rigging
frame”, page 54
Rigging frame
The UDM series multifunctional rigging frame is designed for the Barco UDM projectors, and can not be used
for other equipment.
See rigging frame specific documentation for how to install the projector in to the frame.
Projector and rigging frame is normally delivered complete assembled together if ordered. (See also “Flight
case”, page 78.
The rigging frame without projector weight about ±23 kg (±50 lb).
Image 6–5 Projector installed in the rigging frame.
Flight case and rigging frame
