CompleteStat Setup at Time of Installation
Determine the following information prior to installation.
1. Degrees Scale: °F °C
2. Unit Type: A/C HP
3. Options: A/C – 1H/1C 2H/2C 1H/2C 2H/1C
HP – 1 Stage 2 Stage
4. Economizer: Yes No
5. Fan: Off Delay (seconds) Unoccupied: Auto On Occupied: Auto On
6. Humidity: Dehumidification Yes No
7. Humidity Setpoint:
8. Dehum Span:
9. Electric Strip Heat: Yes No
10. Reversing Valve: Active Htg Active Clg
11. System: Off Cool Heat Auto
12. Cool Setpoint:
13. Heat Setpoint:
14. Cool Setback:
15. Heat Setback:
16. Standby Time: Minutes
17. Motion Sensing: Daily Schedule
18. Date:
19. Time:
20. Occupied Minimum Cooling:
21. Occupied Maximum Cooling:
22. Unoccupied Minimum Cooling:
23. Unoccupied Maximum Cooling:
24. CO
2
Setpoint:
25. CO
2
Span :
NOTES _______________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
