Bartec RLAnet 17-85G5-2123 Series User Manual

10 Assembly and operating instructions / EN
4. Device description
4.1. Module description
Key
Item
Description
Function
1
Display, 4 digits
Description of the location of the
leak (no leaks, distance to the
leak in running meters)
2
Power supply connection
3
Connection alarm relay
4
LED, Modbus RTU communication
(RX = incoming, TX = outgoing)
Display of the interface
communication
5
RS485 communication interface
connection
6
LED, devices and system status
Display of the device and
system status (power, service,
leak)
7
"Confirm" button
Acknowledging error messages
8
Connection sensor cable, 4-wire
Description of the display
---- no leak
12.3 leakage at 12 running meters
err line break
no display no power present
Scope of delivery
1 piece
Monitoring device RLA
net
1 piece
Data sheet/quick guide
Type label
Exemplary depiction of type plate:
8
7
5
4
3
2
6
1
