8 Assembly and operating instructions / EN

3.1. Wiring diagram

Connection as a stand-alone system

Connection of sensors, cables and plugs

Key

Monitoring device RLA

net

SCR sensor line, PS sensor

XS1

Plug/plug-in coupling M12

(BARTEC item 05-0091-0054, item 05-0091-0055)

end

Terminating plug (BARTEC Art. 05-0080-0161)
