Bartec Syscom MR3000C User Manual

43
5.2 Status
This page displays information about the SB. The page is updated automatically.
• ID contains:
o Name of the MR3000SB (by default this is mr3000, followed by a dash and its serial
number). You may change the name, according to your needs (see Section 5.4.1).
o Comment, for example a description of the location where you have installed the SB.
This text is shown together with the name in the messages (see Section 5.4.1).
o UID unit ID (serial number) – can not be changed
o firmware version.
 Sensor tells you for which sensor the SB is configured.
 Activity reports the current activity of the data acquisition services:
o Trigger shows 3 different states:
 idle: the SB is not recording an event
 recording: the SB is currently recording an event
 triggering: one of the trigger conditions is fulfilled and the SB is recording until the
post-event time is elapsed.
o Background: this shows if the SB is currently recording a peak file (file name) or not
(idle).
o FTP backup: shows 4 different states:
 in progress: currently a file is sent to the FTP server.
 errors: errors occurred when communicating to the FTP server.
 idle: service is active, but there is no new file to be copied.
 disabled: service is not active.
o FTP push: shows 4 different states:
 Pushing N files: after starting the service the number of files to be sent is shown.
 N files pending: N files are waiting to be sent in case of trouble or many files have
been recorded recently and have not been transferred yet, eg. due to slow
communication.
 idle: service is active, but no scheduled push is currently going on.
 disabled: service is not active.
o Timed recordings: shows 3 different states:
 active: the SB is either recording (see trigger status above) or in the period
between two scheduled recordings.
 idle: service is active, but start time has not been reached yet.
 disabled: service is not active.
 LAN displays the IP address of the SB on the Ethernet port or FO, and the MAC address of
the interface.

Bartec Syscom MR3000C Specifications

General

Category	Measuring Instruments
Type	Seismic Recorder
Channels	3
GPS Synchronization	Yes
Data Storage	Internal Flash Memory
Communication Interface	Ethernet, USB
Operating Temperature	-20°C to +60°C
Protection Class	IP67
Resolution	24 bit
Sampling Rate	Up to 1000 samples per second
Accuracy	0.1%
Response Time	1 ms

Summary

1. INTRODUCTION

1.1 Features

Details the main capabilities and characteristics of the MR3000SB device.

1.2 Specifications

Lists the operational parameters and environmental limits of the MR3000SB.

1.3 Applications

Outlines the primary use cases for structural monitoring with the MR3000SB.

2. HARDWARE

2.1 Mechanical Drawing – Overview

Provides visual diagrams and dimensions of the MR3000SB unit.

2.2 Connectors

Describes the various input/output ports and their functions on the MR3000SB.

2.3 Status LEDs

Explains the meaning of the status indicator lights on the MR3000SB.

2.4 Opening the Lid

Details the procedure and precautions for accessing the internal components of the MR3000SB.

4. OPERATING WITH THE MR3000SB

4.1 Preparing the SB for field use

Guides on setting up the MR3000SB for deployment and data acquisition in the field.

4.2 Power Options

Explains the different methods for powering the MR3000SB, including battery and mains.

4.3 Additional services

Covers supplementary features like embedded SFTP server for data access.

5. The Web User Interface (WebUI)

5.1 Start

Details how to initiate recording sessions and access recent data via the WebUI.

5.2 Status

Describes how to monitor the operational status and key indicators of the MR3000SB.

5.3 System

Covers configuration of hardware interfaces and software services like LAN, DDNS, and VPN.

5.4 User Parameters

Explains how to configure alerting and general device parameters not related to acquisition.

5.5 VIEW

Describes how to view real-time waveform data and background recording levels.

5.6 Master functionality

5.6.1. Config / Status and Master/slave configuration

Explains how to set up and manage a network of MR3000SB/MR3000C devices.

5.6.2. Common Trigger

Details configuring synchronized trigger events across multiple networked MR3000SB units.

5.7 Recording List

Provides access to stored event files and options for immediate download.

5.8 System warning

Describes how the system alerts users to configuration issues or errors.

5.9 Rest API

Information on the REST API for programmatic interaction with the MR3000SB.

6. Available spare parts and accessories

Appendix A: SAFETY INSTRUCTIONS

Crucial safety guidelines for installation, operation, and handling of the MR3000SB.
