Basler ace User Manual

Specifications, Requirements, and Precautions AW00123401000
4 Basler ace USB 3.0
Specification acA1600-20um/uc acA2500-14um/uc
Sensor Size
(H x V pixels)
gm: 1628 x 1236
gc: 1624 x 1234
gm: 2592 x 1944
gc: 2590 x 1942
Sensor Type Sony ICX274 AL/AQ
Progressive scan CCD
Global shutter
Aptina MT9P031
Progressive scan CMOS
Rolling shutter
Optical Size 1/1.8" 1/2.5"
Pixel Size (H x V) 4.4 µm x 4.4 µm 2.2 µm x 2.2 µm
Max. Frame Rate
(at full resolution)
20 fps 14 fps
Mono/Color Mono or color (color models include a Bayer pattern RGB filter on the sensor)
Data Output Type USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Pixel Data Formats Mono Models: Mono 8
Mono 12
Mono 12p
Color Models: Mono 8
Bayer BG 8
Bayer BG 12
Bayer BG 12p
YCbCr422_8
Mono Models: Mono 8
Mono 12
Mono 12p
Color Models: Mono 8
Bayer GB 8
Bayer GB 12
Bayer GB 12p
YCbCr422_8
ADC Bit Depth 12 bits
Synchronization Via external trigger signal, via the USB 3.0 port or free run
Exposure Control Via external trigger signal or programmable via the camera API
Camera Power
Requirements
(Unless otherwise noted,
maximum values are
indicated for power
consumption).
Nominal +5 VDC, compliant with the Universal serial Bus 3.0 specification, supplied
via the camera’s USB 3.0 port
~ 3.5W @ 5VDC ~2.2 W @ 5VDC
I/O Lines 1 opto-isolated input line, 1 opto-isolated output line, and 2 direct-coupled GPIO
lines
Lens Adapter C-mount
Size (L x W x H) 42.0 mm x 29 mm x 29 mm (without lens adapter or connectors)
48.2 mm x 29 mm x 29 mm (with lens adapter and connectors)
Weight < 80 g
Conformity CE, UL (in preparation), FCC, GenICam v. 2.0, GigE Vision, IP30, RoHS, USB3
Vision, USB-IF (in preparation)
Table 2: General Specifications

Basler ace Specifications

General

Sensor Type	CMOS
Lens Mount	C-mount, CS-mount
Interface	GigE, USB 3.0
Dimensions	29 mm x 29 mm x 29 mm (some models vary slightly)
Operating Temperature	0°C to 50°C
Shutter Type	Global shutter, Rolling shutter
Bit Depth	8-bit, 10-bit, 12-bit
Weight	Approx. 100 g (varies by model)
