1.8 Precautions
For more specific information about the lens thread length, see Section 1.4.2 on page 13.
NOTICE
Avoid dust on the sensor.
The camera is shipped with a plastic cap on the lens mount. To avoid collecting dust on the
camera’s IR cut filter (color cameras) or sensor (mono cameras), make sure that you always put
the cap in place when there is no lens mounted on the camera.
NOTICE
On all cameras, the lens thread length is limited.
All cameras (mono and color) are equipped with a plastic filter holder located in the lens mount.
The location of the filter holder limits the length of the threads on any lens you use with the
camera. If a lens with a very long thread length is used, the filter holder or the lens mount will be
damaged or destroyed and the camera will no longer operate properly.
NOTICE
Voltage outside of the specified range can cause damage.
 You must supply camera power that complies with the Universal Serial Bus 3.0 specification.
The camera’s nominal operating voltage is +5 VDC, effective on the camera’s connector.
NOTICE
An incorrect plug can damage the 6-pin connector:
 The plug on the cable that you attach to the camera’s 6-pin connector must have 6 female
pins. Using a plug designed for a smaller or a larger number of pins can damage the
connector.
NOTICE
Using a wrong pin assignment can severely damage the camera:
 Make sure the cable and plug you connect to the 6-pin connector follow the correct pin
assignment.

Basler ace Specifications

General

Sensor Type	CMOS
Lens Mount	C-mount, CS-mount
Interface	GigE, USB 3.0
Dimensions	29 mm x 29 mm x 29 mm (some models vary slightly)
Operating Temperature	0°C to 50°C
Shutter Type	Global shutter, Rolling shutter
Bit Depth	8-bit, 10-bit, 12-bit
Weight	Approx. 100 g (varies by model)
