Basler ace User Manual

Specifications, Requirements, and Precautions AW00123401000
6 Basler ace USB 3.0
1.3 Spectral Response
1.3.1 Mono Camera Spectral Response
The following graphs show the spectral response for each available monochrome camera model.
The spectral response curves exclude lens characteristics and light source
characteristics.
Wavelength (nm)
Relative Response
Fig. 1: acA640-120um Spectral Response (From Sensor Data Sheet)

Basler ace Specifications

General

Sensor Type	CMOS
Lens Mount	C-mount, CS-mount
Interface	GigE, USB 3.0
Dimensions	29 mm x 29 mm x 29 mm (some models vary slightly)
Operating Temperature	0°C to 50°C
Shutter Type	Global shutter, Rolling shutter
Bit Depth	8-bit, 10-bit, 12-bit
Weight	Approx. 100 g (varies by model)
