AW00123401000 Specifications, Requirements, and Precautions
Basler ace USB 3.0 9
1.3.2 Color Camera Spectral Response
The following graphs show the spectral response for each available color camera model.
The spectral response curves exclude lens characteristics, light source
characteristics, and IR-cut filter characteristics.
To obtain best performance from color models of the camera, use of a dielectric
IR cut filter is recommended. The filter should transmit in a range from 400 nm to
700 ... 720 nm, and it should cut off from 700 ... 720 nm to 1100 nm.
A suitable IR cut filter is built into the lens adapter on color models of the camera.
Wavelength (nm)
Relative Response
Blue
Green
Red
Fig. 5: acA640-120uc Spectral Response (From Sensor Data Sheet)
