Basler DECS-150 User Manual

9492600990 25-23
DECS-150 Modbus
®
Communication
Name
Register
Type
Bytes
R/W
Unit
Range
Generator var Pre-position 3
2280
Float
4
R W
kilovar
Setpoint adjustment range determined
by registers 2244 and 2246.
Generator PF Pre-position Mode 3
2282
Float
4
R W
n/a
Maintain=0 Release=1
Generator PF Pre-position 3
2284
Float
4
R W
Power Factor
Setpoint adjustment range determined
by registers 2260 and 2262.
Active Field Current Regulation Setpoint
2286
Float
4
R W
Amp
Setpoint adjustment range determined
by registers 2212 and 2214.
Active Generator Voltage Setpoint
2288
Float
4
R W
Volt
Setpoint adjustment range determined
by registers 2228 and 2230.
When the With Limit box is checked on
the Auxiliary Input screen in
BESTCOMSPlus, register 2288 equals
register 2216 plus the Aux input.
When the With Limit box is not checked
on the Auxiliary Input screen in
BESTCOMSPlus, register 2288 equals
register 2216.
Active Generator var Setpoint
2290
Float
4
R W
kilovar
Setpoint adjustment range determined
by registers 2244 and 2246.
Active Generator PF Setpoint
2292
Float
4
R W
Power Factor
Setpoint adjustment range determined
by registers 2260 and 2262.
Field Current Preposition Traverse 1
2294
Float
4
R W
Second
0–200
Field Current Preposition Traverse 2
2296
Float
4
R W
Second
0–200
Field Current Preposition Traverse 3
2298
Float
4
R W
Second
0–200
Generator Voltage Preposition Traverse
1
2300
Float
4
R W
Second
0–200
Generator Voltage Preposition Traverse
2
2302
Float
4
R W
Second
0–200
Generator Voltage Preposition Traverse
3
2304
Float
4
R W
Second
0–200
Generator Var Preposition Traverse 1
2306
Float
4
R W
Second
0–200
Generator Var Preposition Traverse 2
2308
Float
4
R W
Second
0–200
Generator Var Preposition Traverse 3
2310
Float
4
R W
Second
0–200
Generator PF Preposition Traverse 1
2312
Float
4
R W
Second
0–200
Generator PF Preposition Traverse 2
2314
Float
4
R W
Second
0–200
Generator PF Preposition Traverse 3
2316
Float
4
R W
Second
0–200
Global Settings
Table 25-10. Global Settings Group Parameters
Group
Name
Register
Type
Bytes
R/W
Unit
Range
PLC Timed Element Settings
Logic Timer 1 Output Timeout
2400
Float
4
R W
Sec
0–1800
PLC Timed Element Settings
Logic Timer 2 Output Timeout
2402
Float
4
R W
Sec
0–1800
PLC Timed Element Settings
Logic Timer 3 Output Timeout
2404
Float
4
R W
Sec
0–1800
PLC Timed Element Settings
Logic Timer 4 Output Timeout
2406
Float
4
R W
Sec
0–1800
PLC Timed Element Settings
Logic Timer 5 Output Timeout
2408
Float
4
R W
Sec
0–1800
PLC Timed Element Settings
Logic Timer 6 Output Timeout
2410
Float
4
R W
Sec
0–1800
PLC Timed Element Settings
Logic Timer 7 Output Timeout
2412
Float
4
R W
Sec
0–1800
PLC Timed Element Settings
Logic Timer 8 Output Timeout
2414
Float
4
R W
Sec
0–1800
PLC Timed Element Settings
Logic Timer 9 Output Timeout
2416
Float
4
R W
Sec
0–1800
PLC Timed Element Settings
Logic Timer 10 Output Timeout
2418
Float
4
R W
Sec
0–1800
PLC Timed Element Settings
Logic Timer 11 Output Timeout
2420
Float
4
R W
Sec
0–1800
PLC Timed Element Settings
Logic Timer 12 Output Timeout
2422
Float
4
R W
Sec
0–1800
PLC Timed Element Settings
Logic Timer 13 Output Timeout
2424
Float
4
R W
Sec
0–1800
PLC Timed Element Settings
Logic Timer 14 Output Timeout
2426
Float
4
R W
Sec
0–1800
PLC Timed Element Settings
Logic Timer 15 Output Timeout
2428
Float
4
R W
Sec
0–1800
PLC Timed Element Settings
Logic Timer 16 Output Timeout
2430
Float
4
R W
Sec
0–1800
PLC Timed Element Settings
Counter 1 Output Timeout
2432
Float
4
R W
n/a
0–1800
