Page #214 background image
25-32 9492600990
Modbus
®
Communication DECS-150
Group
Name
Register
Type
Bytes
R/W
Unit
Range
Configurable Protection 5
Stop Mode Inhibit
3392
Int32
4
R W
n/a
No=0 Yes=1
Configurable Protection 5
Threshold 1 Type
3394
Int32
4
R W
n/a
Disabled=0 Over=1 Under=2
Configurable Protection 5
Threshold 1 Pickup
3396
Float
4
R W
n/a
-999999 999999
Configurable Protection 5
Threshold 1
Activation Delay
3398
Float
4
R W
Second
0–300
Configurable Protection 5
Threshold 2 Type
3400
Int32
4
R W
n/a
Disabled=0 Over=1 Under=2
Configurable Protection 5
Threshold 2 Pickup
3402
Float
4
R W
n/a
-999999 999999
Configurable Protection 5
Threshold 2
Activation Delay
3404
Float
4
R W
Second
0–300
Configurable Protection 5
Threshold 3 Type
3406
Int32
4
R W
n/a
Disabled=0 Over=1 Under=2
Configurable Protection 5
Threshold 3 Pickup
3408
Float
4
R W
n/a
-999999 999999
Configurable Protection 5
Threshold 3
Activation Delay
3410
Float
4
R W
Second
0–300
Configurable Protection 5
Threshold 4 Type
3412
Int32
4
R W
n/a
Disabled=0 Over=1 Under=2
Configurable Protection 5
Threshold 4 Pickup
3414
Float
4
R W
n/a
-999999 999999
Configurable Protection 5
Threshold 4
Activation Delay
3416
Float
4
R W
Second
0–300
Configurable Protection 5
Label
3418
String
16
R W
n/a
0–16
Configurable Protection 6
Parameter
Selection
3426
Int32
4
R W
n/a
Gen VAB=0 Gen VBC=1 Gen
VCA=2 Gen V Average=3 Bus
Freq=4 Bus VAB=5 Bus VBC=6
Bus VCA=7 Gen Freq=8 Gen PF=9
KWH=10 KVARH=11 Gen IA=12
Gen IB=13 Gen IC=14 Gen I
Average=15 KW Total=16 KVA
Total=17 KVAR Total=18 EDM
Ripple=19 Vfd=20 Ifd=21 Auxilary
Input Voltage=22 Auxilary Input
Current (mA)=23 Setpoint
Position=24 Tracking_Error=25
Neg_Seq_V=26 Neg_Seq_I=27
Pos_Seq_V=28 Pos_Seq_I=29
PSS_Output=30 Power Input=49
KW A=50 KW B=51 KW C=52
KVAR A=53 KVAR B=54 KVAR
C=55 KVA A=56 KVA B=57 KVA
C=58 Gen VAN=59 Gen VBN=60
Gen VCN=61 Cross Current=62
GenScaledPF=63 Network Load
Share Error Percent=65 No Param
Selected=64 LVRT Output=66 APC
Output=67
Configurable Protection 6
Hysteresis
3428
Float
4
R W
Percent
0–100
Configurable Protection 6
Arming Delay
3430
Float
4
R W
Second
0–300
Configurable Protection 6
Stop Mode Inhibit
3432
Int32
4
R W
n/a
No=0 Yes=1
Configurable Protection 6
Threshold 1 Type
3434
Int32
4
R W
n/a
Disabled=0 Over=1 Under=2
Configurable Protection 6
Threshold 1 Pickup
3436
Float
4
R W
n/a
-999999 999999
Configurable Protection 6
Threshold 1
Activation Delay
3438
Float
4
R W
Second
0–300
Configurable Protection 6
Threshold 2 Type
3440
Int32
4
R W
n/a
Disabled=0 Over=1 Under=2
Configurable Protection 6
Threshold 2 Pickup
3442
Float
4
R W
n/a
-999999 999999
Configurable Protection 6
Threshold 2
Activation Delay
3444
Float
4
R W
Second
0–300
Configurable Protection 6
Threshold 3 Type
3446
Int32
4
R W
n/a
Disabled=0 Over=1 Under=2
Configurable Protection 6
Threshold 3 Pickup
3448
Float
4
R W
n/a
-999999 999999
Configurable Protection 6
Threshold 3
Activation Delay
3450
Float
4
R W
Second
0–300
Configurable Protection 6
Threshold 4 Type
3452
Int32
4
R W
n/a
Disabled=0 Over=1 Under=2
Configurable Protection 6
Threshold 4 Pickup
3454
Float
4
R W
n/a
-999999 999999
Configurable Protection 6
Threshold 4
Activation Delay
3456
Float
4
R W
Second
0–300
Configurable Protection 6
Label
3458
String
16
R W
n/a
0–16
