9492600990 28-3
DECS-150 Specifications
Terminal Assignments
Watchdog ......................................... WD1, WD2, WD3
Relay Output 1 ................................. OC1, OC1
Relay Output 2 ................................. OC2, OC2
Breaker Shunt Trip Output ............... ST+, ST
Field Power Output
Continuous Rating ............................ 7 Adc (70°C ambient) or 10 Adc (55°C ambient)
Terminals.......................................... F+, F
Minimum 10-Second Forcing Output Rating
120 Vac Input ................................... 100 Vdc, 11 Adc
240 Vac Input ................................... 200 Vdc, 11 Adc
Minimum Field Resistance
63 Vdc Application ........................... 9 Ω
125 Vdc Application ......................... 18 Ω
Regulation
In regulation modes that rely upon the monitoring of the generator terminal voltage and current, the
DECS-150 senses and responds to the measured rms quantities.
FCR Operating Mode
Setpoint Range ................................ 0 to 7 Adc (70°C ambient) or 0 to 10 Adc (55°C ambient) in 0.1 Adc
increments
Regulation Accuracy ........................ ±5.0%
AVR Operating Mode
Setpoint Range ................................ 70 to 120% of rated machine voltage, in increments of 0.1%
Regulation Accuracy ........................ ±0.25% over load range at rated PF with constant machine
frequency and ambient temperature
Steady-State Stability ....................... ±0.25% at rated PF with constant machine frequency and ambient
temperature
Temperature Drift ............................. ±0.5% between 0 and 40°C at constant load and machine frequency
Var Operating Mode
Setpoint Range ................................ 100% (leading) to +100% (lagging) of the machine nominal
apparent power in increments of 0.1%
Regulation Accuracy ........................ ±2.0% of the nominal machine apparent power rating at the rated
machine frequency
Power Factor Operating Mode
Setpoint Range ................................ 0.5 to 1.0 (lagging) and 0.5 to 1.0 (leading), in increments of 0.01
Regulation Accuracy ........................ ±0.02 PF of the PF setpoint for the real power between 10 and 100%
at the rated frequency
Parallel Compensation
Modes Reactive Droop, Line Drop, and Reactive Differential (Cross-Current)
Cross-Current Input Burden ............. Can exceed 1 VA if external resistors are added to the CT circuit for
cross-current compensation
