1 Introduction
1.1 Scope of delivery
Please check the delivery upon completeness prior to commissioning.
Depending on encoder configuration and part number delivery is including:
Basic encoder, bus cover and CD with describing file and manual (also available as download)
1.2 Product allocation and xdd files
1.2.1 Firmware version 1.3.x or lower
Product mechanics
Solid / End shaft / Kit
Product
Code / Name
xdd-file
Description
BMMV / BMMH / BMMK
16h
BMMx
5F_POWERLINK_Rotary_Encoder_BMMx_MT.xdd
MT, MAGRES
BMSV / BMSH / BMSK
17h
BMSx
5F_POWERLINK_Rotary_Encoder_BMSx_ST.xdd
ST, MAGRES
GBMMW / GBMMS / -
0Fh
GBMMx
5F_POWERLINK_Rotary_Encoder_GBMMx_MT.xdd
MT, Optical, 18 Bit ST
GBAMW / GBAMS / -
0Eh
GBAMx
5F_POWERLINK_Rotary_Encoder_GBAMx_ST.xdd
ST, Optical, 18 Bit ST
GXMMW / GXMMS / -
0Dh
GXMMx
5F_POWERLINK_Rotary_Encoder_GXMMx_MT.xdd
MT, Optical, 13 Bit ST
GXAMW / GXAMS / -
0Ch
GXAMx
5F_POWERLINK_Rotary_Encoder_GXAMx_ST.xdd
ST, Optical, 13 Bit ST
1.2.2 Firmware version 1.5.x or higher
Product mechanics
Solid / End shaft / Kit
Product
Code / Name
xdd-file
Description
BMMV / BMMH / BMMK
16h
BMMx
Baumer_EPL_Encoder_BMMx_244.xdd
MT, MAGRES
BMSV / BMSH / BMSK
17h
BMSx
Baumer_EPL_Encoder_BMSx_244.xdd
ST, MAGRES
GBMMW / GBMMS / -
0Fh
GBMMx
Baumer_EPL_Encoder_GBMMx_5EA4.xdd
MT, Optical, 18 Bit ST
GBAMW / GBAMS / -
0Eh
GBAMx
Baumer_EPL_Encoder_GBAMx_5EA4.xdd
ST, Optical, 18 Bit ST
GXMMW / GXMMS / -
0Dh
GXMMx
Baumer_EPL_Encoder_GXMMx_5EA4.xdd
MT, Optical, 13 Bit ST
GXAMW / GXAMS / -
0Ch
GXAMx
Baumer_EPL_Encoder_GXAMx_5EA4.xdd
ST, Optical, 13 Bit ST
Explanation:
MT Multiturn encoder
ST Singleturn encoder
MAGRES Extremely robust encoder with magnetic sensing principle
18 Bit ST High resolution encoder – up to 18 bit physical singleturn resolution, i.e. 2
18
steps / revolution
13 Bit ST Max. 13 bit physical singleturn resolution, i.e. 2
13
steps / revolution
