5 Technical specifications
5.1 Powerlink specifications
The bus cover complies with following specifications:
Powerlink version
2.0
CANopen profile
CiA 406 (encoders)
Minimum cycle time:
250µs
5.2 Ethernet specifications
MTU
300 Bytes
Delay internal Hub (Daisy Chain)
400ns/Node
Max. Response Time
2 µs (incl. hub delay)
Transmission rate
100 MBit/s semi-duplex
Ethernet outputs
2 outputs: M12 D-coded (Auto-Negation)
5.3 Timing behavior
The following table describes the delay and jitter between the Start of Cycle (SoC) and acquisition of a new
position value.
Product
Delay typical
Jitter
BMSx (ST):
BMMx (MT):
GXAMx (ST):
GXMMx (MT):
GBAMx (ST):
GBMMx (MT):
11,34µs
13,84µs
5,00µs
5,00µs
7,20µs
7,20µs
+- 7,6µs (=7,5µs +/- 68ns)
+- 10,1µs (= 10µs +/- 68ns)
+- 0,6µs (= 0,54µs +/- 68ns)
+- 0,6µs (= 0,54µs +/- 68ns)
+-1,3µs (= 1,2µs +/- 68ns)
+-1,3µs (= 1,2µs +/- 68ns)
5.4 Physical resolution for each product
The following table describes the non-scaled physical resolution dependent on the used basic encoder.
Encoder
Product Name
ST Resolution
MT Resolution
Total Resolution
BMS ST
BMSx
4000h
14 Bit
-
4000h
14 Bit
BMM MT
BMMx
4000h
14 Bit
4 0000h
18Bit
1 0000 0000h
32 Bit
GXAM ST
GXAMx
2000h
13 Bit
-
2000h
13 Bit
GXMM MT
GXMMx
2000h
13 Bit
1 0000h
16Bit
2000 0000h
29 Bit
GBAM ST
GBAMx
4 0000h
18 Bit
-
4 0000h
18 Bit
GBMM MT
GBMMx
4 0000h
18 Bit
4000h
14Bit
1 0000 0000h
32 Bit
