Mode
Level 3: Output Logic
Level 4: Factory Reset
Xpert Static
Enter teach Level by activating
qTeach >6 .. <8 sec.
(Green & yellow LED flash with 2 Hz)
Tap qTeach to change the logic
indicated by the LEDs
Green LED: Normal
Yellow LED:Inverted
Enter teach level by activating
qTeach >8 … <12 sec.
No further actions required
Xpert Dynamic
Enter teach Level by activating
qTeach >6 .. <8 sec.
(Green & yellow LED flash with 2 Hz)
Tap qTeach to change the logic
indicated by the LEDs
Green LED: Normal
Yellow LED:Inverted
Enter teach level by activating
qTeach >8 … <12 sec.
No further actions required
Xpress Static
One Step Teach
N/A
N/A
Xpress Dynamic
One Step Teach
N/A
N/A
