14 Operating Manual OM20/ OM30 RS485 with Modbus RTU | V1
Address
Number of
registers Command Description
400 2 Trigger Mode Configure trigger mode
402 2 Fix Time Trigger Interval Time period for Interval trigger mode
410 1 Laser ON/OFF Switch laser on and off
411 1 Teach Lock Time until the Teach button is deactivated
412 1 Teach Pattern Parameterize the mode of the Teach but-
ton
503 1 Sensor Reset Reset the sensor to the factory settings
800 1 Dropout Timeout Holding time for invalid measured value
1000 1 Reset All Statistics Reset all statistical data (operating time,
histograms)
1001 1 Reset Operation Time Reset operating time
1002 1 Reset Distance Histogram Reset histogram for distance
1003 1 Reset Exposure Reserve
Histogramm
Reset the histogram for exposure reserve
1050 16 App Specific Tag Customer-spec. identification of the sen-
sor
1066 16 Function Tag Customer-spec. identification of the sen-
sor
1082 16 Location Tag Customer-spec. identification of the sen-
sor
1100 1 Modbus Slave Address Slave address
1101 1 Modbus Baudrate ID Baud rate
1102 1 Orange LED function Parameterize function of the LED
Input register: function ID 04
Address
Number of
registers Command Description
0 16 Vendor Name Manufacturer name
16 16 Vendor Text Manufacturer note
32 26 Product Name Product name
58 5 Product ID Item number
63 32 Device Text Product text
95 10 Serial Number Serial number
105 5 Hardware Revision Hardware version
110 5 Firmware Revision Firmware version
115 6 P-Code Production code
200 13 All Measurement Values Measured value and additional information
301 2 Operation Time: Powerup Operating time since the sensor powered
up
303 2 Operation Time: Resetable Operating time since a defined point in
time
