Baumer OM20 - Dimensional Drawing; Ill. 3 Dimensional Drawing OM20; Ill. 4 Dimensional Drawing OM30

3 | Description Baumer
16 Operating Manual OM20/ OM30 RS485 with Modbus RTU | V1
3.6 Dimensional drawing
13
34,5
37
M8 x 1
2,9 11,2 19
31,6
LED
Teach-in
26
3,2
3
2,2
2
7,7
Ill.3: Dimensional drawing OM20
13,6
49
4,2
3,9 41
M8 x 1
6,429
40,3
Teach-in
LED
2
9,7
Ill.4: Dimensional drawing OM30
