7 Commissioning
7.1 Factory settings
Adjustable parameters Factory setting in the sensor
Communication Parameter Modbus Slave Address 1
Baudrate 57600
Operation Mode Precision Filter Highest
Sampling Mode Free Running
Measurement Range Zero Position 0 mm
Distance Near Sdc
Distance Far Sde
Invalid Value Handling Hold Time 0 ms
SSC1 Configuration SP 1 Sde -10 mm
I
SP 2 Sdc +10 mm
II
Polarity Active High
Mode Window
Hysteresis depending on MR
Input/Output Settings LED function SSC1 - Alarm
Local User Interface Local Teach Mode XPert
Button Time Out 5 min
I
Type OM20-P0026.xx.xxx: SSC1 Param.SP 1 = -2mm
II
Type OM20-P0026.xx.xxx: SSC1 Param.SP 2 = +2mm
