Baumer Diagnostic data | 9
OM20/ OM30 RS485 with Modbus RTU | V1 Operating Manual 47
Modbus RTU command – input register: exposure reserve histogram function
Address 353 – Histogramm Exposure Reserve: Range Start
Address Access
Number of
registers Data type Description
353 Read 2 uint32_t Start of valid range
Address 355 – Histogramm Exposure Reserve: Range End
Address Access
Number of
registers Data type Description
355 Read 2 uint32_t End of valid range
Address 357 – Histogramm Exposure Reserve: Number of Bins
Address Access
Number of
registers Data type Description
357 Read 1 uint16_t Number of bins
Address 359 – Histogramm Exposure Reserve: Bin 1 - 20
Address Access
Number of
registers Data type Description
359 Read 40 uint32_t Bin 1 - 20
Modbus RTU command – holding register: exposure reserve histogram function
Address 1003 – Reset Exposure Reserve Histrogramm
Address Access
Number of
registers Data type Description
1003 Write 1 x Reset the histogram (exposure re-
serve): Call up the function by writ-
ing any number.
