Baumer PA408 Operating Instructions

PA408
www.baumer.com
29
3.4 Wiring examples
Input process voltage ±10V
4-wire sensor,
external supply
Process display
V-
Sensor
V+
OUT+ OUT-
V IN+
IN-
External
sensor
supply
-
+
3-wire sensor,
external supply
V+
Sensor
OUT+ OUT-
External
sensor
supply
+
-
Process display
V IN+
IN-
4-wire sensor,
device supplied
Process display
V-
Sensor
OUT+ OUT-
V IN+
IN-
Sensor-
V+
Sensor+
Standard signal input current
4-wire sensor,
external supply
Process display
V-
Sensor
V+
OUT+ OUT-
I IN+
I IN-
External
sensor
supply
-
+
3-wire sensor,
external supply
V+
Sensor
OUT+ OUT-
External
sensor
supply
+
-
Process display
I IN+
I IN-
2-wire 4-20 mA sensor,
external supply
V+
Sensor
OUT+ OUT-
External
sensor
supply
+
-
Process display
I IN+
I IN-
2-wire 4-20mA sensor
V+
Sensor
OUT+
Sensor+
Process display
I IN+
In the example below, sensor supply is by device current loop.
