PA408
38
www.baumer.com
Technical data - mechanical design
Ambient temperature -10...+60 °C
Storing temperature -25...+85 °C
Relative humidity 95 % non-condensing
Connection Spring-loaded terminal connector,
detachable
Core cross-section 1 mm² (grid 5.08)
2.5 mm
2
(grid 7.62)
Protection DIN EN 60529 IP 65 (face)
Operation / keypad Membrane with softkeys
Housing type Built-in housing
Dimensions W x H x L 96 x 48 x 66 mm
Mounting Front panel installation by clip frame
Material Housing: Polycarbonate, UL94V-0
Weight approx. 150 g
7. 1 Dimensions
PA408 - without clip frame
PA408 - clip frame mounting
