TROUBLESHOOTING GUIDE
Nopowertothegame
Nolights
Checkwalloutlet
Resetpowerstripbreakerswitchorbuilding
Circuitbreaker
Changepluglocaon,replaceifneeded
BillAcceptorpowerson.
Buteverythingelseo.
(PowerSupplynotON)
MakesurerockerswitchissetON.()andswitchat
100Vor230V
Seepowersupplydiagnoscstoisolatebadcompo
nent.Abadmotoror12voltshortwouldcause
this.
Gamenotcoiningup Checkcoinswitches—bothshouldbewirednor
mallyopen.Ifoneswitchis“closed”theotherwill
notworkeither.
Checkwiringtominigenboard.
CheckPayIn/OutMenu.EnsureCreditsperGame
isset.Default=4
Nosound
Motherboardcreatessound,MiniGenboard
ampliesit.
EnterMainMenuandverify:GameVolume&
AractVolumearenotzero
Checkconneconsandreseataudiocablefrom
motherboardtoMiniGenbard
Unplugaudiojackcable(A5CEAU010)frommoth
erboard,plugintoMP3playerandseeifmusicis
ampliedandcomesoutofspeaker.
IfYesthenmotherboardisfaulty.
IfNothenMiniGenboardmaybefaulty.
Replacespeaker.AACE8811
