POWER SUPPLY DIAGNOSTICS
VerifyACpowertogame.
1.)Checkpowerstripinfrontdoor.Therockerswitchshouldbeilluminated.
2.)Checkconnecontopowersupply.
3.)EnsurePowerSupplyswitchissetto115V(or230V)
(Somemodelpowersuppliesmaynothavethis)
4.)EnsurePowerswitchison.
5.)Ensurefanisturning.
Ifpowersupplyfanisturningandthereisno12Voltout,thenreplacepowersupply.(AAPS1008GB)
Ifpowersupplyfanisnotturning,thenconnueto“VerifyPowertoMotherboard”
VerifyPowertoMotherboard
Themotherboardwillturnonpower supply.
Ifyourgamehasno12volts,itmaybethemotherboardnotturningon.
Inaddiontheremaybea12voltshortsomewhereelseincabinetthatisnotallowingthepowersupplyto
turnon.
Minimizeloadonpowersupplyandisolateshort
Unplugalloutputsfrompowersupplyexceptformotherboard.
Thiswillhavepowersupply,motherboard,andmonitorlepluggedin.
Ifpowersupply,motherboard,andmonitornowturnon:
Pluginonecomponentatametopowersupplytolocateshort.
Ifpowersupplyslldoesnotpowero n ,thenconnuetosteps1,2,and3.
