27
WIRING DIAGRAMS
DEBIT CARD SYSTEM SETUP
Option #1:
New card swipe systems may come with a standard 9 pin Molex
connector.
Simply unplug this connector and plug into your card swipe reader.
AACE2801
AACE2801
Option #2:
If your card swipe systems does not have a standard 9
pin Molex connector, then you will have to splice wires into
the AACE2801 harness.
AACE2801
AACE2801
If you have to splice the wires, use
these two
To Next Page
