Bay Tek Games Quick Drop - Page 26

26
WIRING DIAGRAMS
MARQUEE LIGHTING, COIN MECH & TICKET DISPENSERS
These con-
nectors are
colored Blue
‐+
‐+
‐+
‐+
AACE5848
LED’s in
the back of
Marquee
AACE5830
‐+
AACE5849
LED’s around
back of Marquee
‐+
AACE5850
LED’s around
side of Marquee
4
3 1
2
AACE5838
12 Volts from
Power Supply
Low
Ticket
Switch
AACE5822
To J21
Connector
AACE5818
AACE5809
To Bill Acceptor
Part # A5AC9091
Power from
Outlet Strip
To Ticket Dispenser
Part # A5TD1
12 Volt Power
Enable Signal
Com Ground
Notch Signal
AACE5818
AACE5815
AACBL4A-DOOR
CoinSwitchesandLights
To J6 Connector
To Tix1 Connector
To J8 (DBA) Connector
AACE5815
This ICL connector
is to be used for
card swipe systems
AANEWGEN1-PJ/RBN
