65
BLANKING PLATES AVAILABLE
A5PL4200 DBA Plate used for Upstacker Bill Acceptor
A5PL9998 Plate used instead of Coin Mechanisms
A5PL8900 Plate used for Bill Validator
A5PL9995 Plate used instead of ticket dispenser
HOW TO REPLACE TARGET PINS
The target pins may break over time, to replace:
Unplug the game from the wall outlet.
Unlock and remove the back door of the game.
Remove the 30 screws in the black plastic panel using a
Phillips screwdriver.
Remove the black plastic panel to expose the back of the
pins.
Use a vise grips or wrench to wiggle the pin straight out of
the back of the panel.
Insert the new pin, and replace the black plastic panel.
Red Target Pin Finger is part # A5PL29000B
White Target Pin Finger is part # A5PL29001B
Blue Target Pin Finger is part # A5PL29002B
