HOW TO TENSION CONVEYOR
The fabric on the conveyor will stretch over time.
If the conveyor belt starts slipping or stops completely, follow
these steps to re-tension the belt.
Tools needed:
14mm socket
There will tensioning mechanisms on both sides of the front
of the belt. They are accessed from the axe return tray -
from the angle of the arrows.
Turning the bolt clockwise will tighten the belt, turn counter-
clockwise will loosen the belt.
Tension both sides of the mechanism the same amount.
The Conveyor Guard is designed to keep fingers from getting pinched by the conveyor roller.
It is very important to adjust this metal bracket at game install, and anytime the game is moved,
conveyor is adjusted or taken apart.
Use a Phillips screwdriver to loosen the 3 bolts.
Move bracket up very close to the conveyor belt and tighten screws.
Make sure the bracket does not touch the conveyor belt, but is close to it.
HOW TO ADJUST CONVEYOR GUARD
To Next Page
