14
The Network Setup menu will appear differently for different card
swipe systems.
Properly enter the “PH Ticket Server IP” - this is the IP address of
the server the Prize Hub goes out and communicates toward.
It is the IP address of the card swipe server itself.
Please refer to appropriate Card System Setup instructions.
The Prize Hub is a DHCP client and needs to communicate with a DHCP server.
It is advisable to take a picture of this screen, because once it is touched, the information will
disappear and prompt you to enter a new IP.
PH Ticket Server Port # must also be entered correctly.
This menu is not used for Kiosk Input Types of Evolve System (Honeywell) and Deltronics Receipts.
NETWORK SETUP MENU
STATISTICS MENU
Statistics Menu:
The statistics menu will help you to determine how many tickets and prizes have
been exchanged and their total value, as well as which prizes are popular.
Page #1 and #2 are resettable and show current statistics
Page #3 are non-resettable and show lifetime statistics
Reset Statistics: Clears all stats in this menu to 0, with the exception of the NR
(non-resettable) page (3/3)
Current Time: This can be changed in the “Location Setup
Menu”
Tickets Total: Total number of incoming tickets
Tickets Comped: Total number of tickets added in “Ticket
Menu”
Tickets Redeemed: Total ticket value of outgoing prizes
Tickets Printed: Total ticket value dispensed via receipt
Total Prizes Vended: Number of prizes dispensed
Total Cost of Prizes: Net value of outgoing prizes; value of
each prize can be set in prize menu
Total Prizes Vended: Number of prizes dispensed
Prize Locations:
Vended (page 1): Total number of specific prize location vends
Failures (page 2): Number of times prize failed to vend (due to being too far
apart on spindles, empty locations, prize jams, etc.)
NRVend (page 3):
Displays a non-resettable statistic of all vends the machine has ever performed
