32
Core
The are 3 different versions of Core Readers:
Core,2,4 - Mag Card Swipe
Core,1,1 - Bar Code /Scanner
Core,10,4 - RFID technology
Plug in an Ethernet cable to the port shown on the
main board (inside the Main Hub), and out
through the hole in the bottom of the cabinet.
Mount your card reader according to manufacturer
instructions, and plug the Ethernet cable into your
card reader server.
Adjust the Kiosk Interface in the location menu to
one of the following:
Core,2,4 for Mag Card Swipe
Core,1,1 for Bar Code /Scanner
Core Size 8,1,1for Bar code scanner
Core,10,4 for RFID technology
Enter Network Setup Menu
Please leave the Prize Hub Network disabled.
Set the Card Server. This is IP address of your
server. It should be in a similar format as shown.
Note: It is important to note if the IP address has a
leading 0 in the octet.
So in this example:
064.126.017.030 is NOT the same as 64.126.17.30
Please be aware and type it in the Prize Hub exactly
as you are given by the card swipe company.
Set Port number. This is the port number of your
server. It should be in a similar format as shown.
CORE CASHLESS OPTIONS
Part # AAKIT-PH-READER
Part # AAKIT-PH-READERCOREB
Assembly
Part # AAKIT-PH-RFID
Includes: plate and decal
Used with any RFID reader.
