53
MOTHERBOARD WIRING DIAGRAM
Note: Make sure
paper is loaded with
watermark showing
on top side.
A5SC1800
Scanner
AAMB7-HD
A5CE6602
USB Access Point
Connects to Motherboard
to load pictures
USB Scanner
Connects to Motherboard
for communication.
AAPRTH002-PH
USB Printer with cutter.
Connects to Motherboard for communication.
USB Communication
A5CORD14
A5CORD20
VGA Cable
to Monitor
AAMO1810
Touchscreen
Monitor
A5CORD14
USB Touchscreen to
Motherboard for
communication.
