Bay-Tek quik drop User Manual


PART # DESCRIPTION
PART # DESCRIPTION
PARTS LIST
220 Version Game Differences
456*-7485
4''''&
AABA5802-P70 Set Of 70 Red Balls
A5BA5801 Ball, Red,Smooth, 3"
AABK1013  Bracket, Pushbutton/Counters
A5BR1001  Bearing
A5BR5800  Bearing, Solenoid Guide
A5CA1005  Caster,250# Load, Swivel/Lock
A5CB1499  Coin Box, White
A5CH1800  Chain,#35,88 Links Long
A5CL1004  Clamp, Versa Latch
A5CL3200  Clamp, Conn, 3/8"
A5CO4203  Cover, Speaker Grill
A5DE0042  Decal, Menu/Volume Decal
A5DE0048  Decal, Universal Card Link
A5DE5800  Decal, Button Platform
A5DE5801  DECAL,CONTROL Panel
A5DE5802  Decal, Cab Front
A5DE5803  Decal, Cab Front
A5DE5804  Decal, Cab Front
A5DE5805  Decal, Side Panel
A5DE5806  Decal, Marquee
A5DE5808  Decal, Backlit Marquee
A5DE5809  Decal, Cab Side, Left
A5DE5810  Decal, Cab Side, Right
A5DE5811  Decal, Instruction Panel, Left
A5DE5812  Decal, Instruction Panel Right
A5DE5813  Decal, Wheel Ramp
A5DE5814  Decal, Jackpot Cover
A5DE5815  Decal, Default Score Card
A5DE5817  Decal, Custom Ticket Set
A5DE5819  Decal, Jackpot Instruction
A5DE5821  Decal, Notice Clean Sensors
A5DEWH010  Decal, White
A5FC0080  Ferrite, Suppressor
A5FI9010  Filter, Inline
A5FO5800  Foam, .5x4x6, Auger Disp Assy
A5GR5800  Grommet, Rubber
A5HO1003  Holder, For Light Bars
A5LI0003  Light, 9 Watt, 60w
A5LK2001  Lock, Cash Box, A05/E00 Key Code
A5LK5002  Lock, 7/8", H95 Key Code
A5ME1878  Metal,3/8 Diax4"Lg Rod
A5ME5800  Metal, Front Corner
A5ME5801  Metal, Side Corner
A5ME5802  Metal, Window Brkt
A5ME5803  Metal, Ball Shear Plate
A5ME5804  Metal, Gear Motor Bkt
A5ME5805  Metal, Solenoid Brkt
A5ME5806  Metal, Playfield Motor Bkt
A5ME5812  Metal, Playfield Shaft Assy
A5ME5813  Metal, Solenoid Link
A5ME5814  Metal, Inner Window Rail Assy
A5ME5815  Metal, Angled Ball Ramp
A5ME5816  Metal, Wheel Shield
A5ME5817  Metal, Ball Counting Bracket
A5ME5818  Metal, Sensor Bracket
A5ME5819  Metal, Solenoid Bracket
A5ME5820  Metal, Encoder Sensor Bkt
A5ME5821  Metal, Top Encoder Brkt
A5PI5801  Pin,Spring,1/8" X 2 1/2" Lg
A5PI5802  Pipe, Pvc Clear, Ball Release
A5PI5803  Pipe, Pvc, Clear, Upper Loader
A5PL4200  Plate, Upstacker Bill Acceptor Plate
A5PL8900  Plate, Bill Validator Blanking Plate
A5RO5800  Rocker, Ball Release
A5RVCI015  Rivet, 5/32x25/64 Red
A5SP1006  Sprocket,#35x10 Tooth
A5SP1801  Spring, Ext, W/Loop Ends
A5SP5801  Sprocket,1"Bore,Crsel Motr,48tooth
A5TR5800  Trim, Rubber Edge
A5TT4000  Ticket Tray
A5VF5800  Vacuum Form, Ring
AAPS1011-QD  Power Supply
