MX87QD User’s Manual
32 MX87QD User’s Manual
1.6.2.2 MiniPCI express slot
The MiniPCIe express slots support Mini cards for WiFi , Bluetooth, COM, USB modules,
and other cards that comply with the mini Card Rev. 1.2 specifications . The figure below
shows the type of full size MiniPCIe / SSD card that can be installed on the top MiniPCI
express slot. Half size MiniPCIe card can be installed on the bottom MiniPCI express slot.
