1.7.2 AT/ATX Power Mode Select (PSON1)
This jumper allows you to select ATX Mode or AT Mode.
ATX MODE (Default) AT MODE
AT Mode: When DC-In power is applied, system will power on automatically.
ATX Mode: Power button is required to power on system.
1.7.3 Chassis Intrusion Connector (JCASE1)
