MX87QD User’s Manual
20 MX87QD User’s Manual
1.3.5 Internal Connector
Internal Connector
Label Function Note Page
CPU_FAN1 CPU Fan Connector 4 x 1 wafer, pitch 2.54mm 38
SYS_FAN1 System Fan Connector 4 x 1 wafer, pitch 2.54mm 38
F_PANEL System Panel Connector 5 x 2 header, pitch 2.54mm 39
ATX12V1 DC Power Connector 2 x 2 Mini-Fit Jr header,
4.20mm
40
COM 1,2,3,4 Serial Port Connector 1,2,3,4 5 x 2 wafer, pitch 2.00mm 41
JDIO1 Digital I/O Connector 10 x 2 header, pitch 2.54mm 41
LPT1 Parallel Port Connector 13 x 2 header, pitch 2.00mm 42
KBMS1 PS/2 KB/MS Connector 6 x 1 wafer, pitch 2.54mm 42
JLVDS1 Low-Voltage Differential
Signaling Connector
20 x 2 wafer, pitch 1.25mm
(Hirose:DF13-40DP-1.25V(91))
43
JBKL1 LCD Inverter Connector 5 x 1 wafer, pitch 2.00mm 44
USB56/78/910 USB 2.0 Connector 5 x 2 header, pitch 2.54mm 44
FP_AUDIO1 Front Panel Audio Connector 5 x 2 header, pitch 2.54mm 45
JAMP1 Amplifier Connector 4 x 1 header, pitch 2.54mm 45
SATA1~4 Serial ATA Connectors 1~4 7-pin header 46
SATAPW1~2 SATA Power Connectors 1~2 4 x 1 wafer, pitch 2.54mm 46
