MX87QD User’s Manual
18 MX87QD User’s Manual
1.3.3 Motherboard Layout
1.3.4 Layout Content List
Slots & socket
Label Function Note Page
LGA1150 LGA1150 socket
DIMMA1 204-pin DDR3 SODIMM Slot A1 27
DIMMB1 204-pin DDR3 SODIMM Slot B1 27
PCIEX16 PCIe x16 Slot 31
MINI_CARD Mini-PCIe Slot 32
