Onboard I/O Headers
SATA 5 x Std. SATA Connectors
USB 4 x USB Headers (8 ports on headers)
RS232 4 x Headers
LPT 1 x Header
SPDIF 1 x Header
Front Audio 1 x Header
Amplifier 1 x Header
Front Panel 1 x Header
Fan Header 3 x Headers (4-pins)
Chassis Intrusion Header 1 x Header
LANLED 1 x Header
Onboard Jumpers
COM Port Ring-In/ Power Select 4 x Headers provides Selection of “Ring-In”, or “12V” or “5V” on COM port
AT/ATX Select 1 x Header
Clear CMOS 1 x Header
Back I/O Panel
PS/2 Keyboard /Mouse 1 x DIN 6 Stack up Connector
VGA 1 x DB 15 Connector
DVI 1 x DVI Connector
HDMI 1 x HDMI Connector
USB2.0 6x Stack up USB Connector
LAN and USB 2 x Stack up RJ45 and USB Connectors
Audio 1 x 3 Jacks Audio Connector (Line-in, Line-Out, Mic)
E-SATA 1 x E-SATA Port
Power & Connector
1 x Std. 24 pin ATX Connector
1 x 4 pin ATX 12 Connector
Form Factor
uATX 9.6” x 9.6”
