BCM RX67Q - Back Panel Connectors

21
• 1.5.5.4 Back Panel Connectors
Label Function Note Page
KBMS PS/2 keyboard and mouse 6-pin Mini-Din 37, 38
HDMI1 HDMI Connector x 1 37, 38
VGA_DVI1 VGA Connector x 1
DVI Connector x 1
D-sub 15-pins, female
Dual Link DVI-D; 24-pins
37, 38
ESATA+USB01 ESATA Connector x 1
USB Connector x 2
37, 38
LAN1_USB23 RJ-45 Ethernet Connector x 1
USB 3.0 Connector x 2
37, 38
LAN2_USB45 RJ-45 Ethernet Connector x 1
USB Connector x 2
37, 38
AUDIO Line-in Port, Line-out Port,
Microphone Port,
5.1 Channel Audio I/O (3 jacks) 37, 38
